UB1500-30GM-U-V1
Winston
M30 Ultrasonic Sensor 15m Distance Position Sensor (UB1500-30GM-U-V1)
Technical Parameters
| UB1500-30GM-U-V1 | ||||||||
| Technical data | ||||||||
| Sensing distance | 65…1500mm | |||||||
| Adjustment range | 70…1500mm | |||||||
| Unusable area | 0…65mm | |||||||
| Standard target plate | 100mm×100mm | |||||||
| Transducer frequency | About 175kHz | |||||||
| Response delay | About 65ms | |||||||
| Indicators/Operating means | ||||||||
| LED blue | Power on | |||||||
| LED yellow | indication of the switching state Flashing: program function object detected | |||||||
| LED red | permanently red: Error Red,flashing: program function,object not detected | |||||||
| Electrical specifications | ||||||||
| Operating voltage UB | 10…30VDC,ripple10%ss | |||||||
| No-load supply current | ≤45mA | |||||||
| Output | ||||||||
| Output type | 1 analogue output 0…10V | |||||||
| Resolution | 0.35mm at max.sensing range | |||||||
| Deviation of the characteristic curve | ±1% of full-scale value | |||||||
| Repeat accuracy | ±0.1% of full-scale value | |||||||
| Load impedance | 1K Ohm | |||||||
| Temperature influence | ±1.5% of full-scale value | |||||||
| Mechanical specifications | ||||||||
| Protection grade | IP67 | |||||||
| Connection | connector(M12×1),4-pin | |||||||
| Material Housing | brass,nickel-plated | |||||||
| Transducer | epoxy resin/hollow glass sphere mixture; foam polyurethane,cover PBT | |||||||
