| Heating element | PTC resistor - temperature limiting |
| Surface temperature | max. 80°C (176°F), except upper protective grille |
| | at 20°C (68°F) ambient temperature |
| Air outlet temperature | max. 110°C (212°F), 50mm above the grille |
| Temperature safety cut-out | to protect against overheating in case of fan failure, |
| | automatic reset |
| Axial fan, ball bearing | air flow 63m⊃3;/h, free flow |
| | service life 70,000h at 25°C (77°F) |
| Connection | male power insert connector according to IEC320 C18 |
| Fuse | 10A time lag (T) integrated in connector - exchangeable |
| Casing | plastic according to UL94 V-0, black |
| Mounting | clip for 35mm DIN rail, EN 60715 or |
| | screw fixing (M5), tightening torque 2Nm max. |
| Fitting position | airflow direction up |
| Dimensions | 150.5 x 88 x 66mm |
| Weight | approx. 0.5kg |
| Operation/Storage temperature | -40 to +60°C (-40 to +140°F) / -40 to +70°C (-40 to +158°F) |
| Operation/Storage humidity | max. 90% RH (non-condensing) |
| Protection type/Protection class | IP20 / II (double insulated) |
| Approvals | |
