CSL 028 CSL028
Winston
Compact Design
Quiet operation
DIN rail or screw mount available
Touch-Safe Fan Heater
Heating power adjusts to ambient temperature
.
The CSL 028 fan heater prevents formation of condensation and provides an evenly distributed
interior air temperature in enclosures. The heater is connected using the internal terminal con-
nectors. The surface temperatures on the accessible side surfaces of the housing are minimized
as a result of the heater design. The CSL 028's small size make it ideal for use in enclosures
where space is at a premium.
| Heating element | PTC resistor - temperature limiting |
| Surface temperature | 250 W: max. 122 °F (50 °C) except upper protective grill, |
| 400 W: max. 149 °F (65 °C) except upper protective grill; | |
| measured at 68 °F (20 °C) ambient temperature | |
| Housing | plastic, UL 94V-0, black |
| Axial fan, ball bearing | service life 40,000 h at 104 °F (40 °C) |
| Air flow, free blowing | 32 cfm (54 m³/h) at AC 120 V; |
| 26 cfm (45 m³/h) at AC 230 V | |
| Connection | 2-pole terminal AWG 14 max. (2.5 mm²) with strain relief, |
| screw torque 0.8 Nm max. | |
| Mounting | clip for 35mm DIN rail, EN 50022 |
| Fitting position | vertical |
| Operating/Storage temperature | -49 to +158 °F (-45 to +70 °C) |
| Protection type/Protection class | IP20 / II (double insulate |
| Art. No. | Operating voltage | Heating capacity | Inrush current max. | Dimensions (H*W*D) | Mounting |
| 02810.0-00 | 230VAC, 50/60Hz | 400W | 15A | 3.54 *3.35*4.37” (90*65*111 mm) | DIN clip |
| 02810.0-01 | 230VAC, 50/60Hz | 400W | 15A | 5.08*3.35*4.37” (129*65*111mm) | Screw mount |
| 02810.9-00 | 120VAC, 50/60Hz | 400W | 9A | 3.54 *3.35*4.37” (90*65*111 mm) | DIN clip |
| 02810.9-01 | 120VAC, 50/60Hz | 400W | 9A | 5.08*3.35*4.37” (129*65*111mm) | Screw mount |
| 02811.0-00 | 230VAC, 50/60Hz | 250W | 9A | 3.54 *3.35*4.37” (90*65*111 mm) | DIN clip |
| 02811.0-01 | 230VAC, 50/60Hz | 250W | 9A | 5.08*3.35*4.37” (129*65*111mm) | Screw mount |
| 02811.9-00 | 120VAC, 50/60Hz | 250W | 6A | 3.54 *3.35*4.37” (90*65*111mm) | DIN clip |
| 02811.9-01 | 120VAC, 50/60Hz | 250W | 6A | 5.08*3.35*4.37” (129*65*111 mm) | Screw mount |
PS: If you can't find the exact type of your product.Please don't rush to go away.Contact me and your questions will be replied ASAP.Thank you for your time.
