WST-8000 / SK3110
Winston
Mechanical / Electronic Heater Thermostat For Controlling Fan Filter And Heater (WST-8000 / SK3110)
Product description
1.Large setting range |
2.Small size,Simple to mount |
3.High switching performance |
4.Time-saving connection ,terminal block could be installed with screw form outside |
5.Easy installation, could be installed to 35mm din rail vertically or horizontally. According to EN50022,it could be clipped to NS/35-ES cabinet profile with its accessory adapter. |
Technical Parameters
Model | Specification |
WST-8000 | KL5-3(Heating) AC10(4)A DC=30W |
KL5-4(Colling) AC5(4)DA DC=30W | |
(D)=sensitivity load at cosθ=0.6 | |
Adjusting range:+5 to +60 | |
Weight:105g appr | |
Size:70*70*33.5 | |
Switch discrepancy:1k 0.8k | |
Voltage:24V to 230V |
Overall dimensions
Packing&Shipping
