BZJ-311 Color Mark Sensor Optical Switch With Ce

Availability:
Quantity:
  • BZJ-311

  • WINSTON

Technical Data

Compact volume
Wide voltage range
Diversified exterior structures

high precision of repeated location

Good performance of anti-interference.

Dust proof,vibration proof,waterproof and Oil-proof.



Model BZJ-311
Supply voltage 10-30VDC
Ambient temperature 0-50ºC
Detecting method Coaxial reflection
Sensing distance 9mm
Chromatogram of light Red, Green, Blue, White
Facula Circular
Response time 50us
Output current <200mA
Output type NPN,Analog Output
Shell material Metal
Cable length 2M
Protection RP-power protection,load short-circuit protection
Dimension 38*62*100mm
Weight 500g
