LMF2
Winston
LMF2 | Detection Distance | 5mm | |||
Flush | DC 6-36VDC | NPN | NO | LMF2-3005NA | |
NC | LMF2-3005NB | ||||
PNP | NO | LMF2-3005PA | |||
NC | LMF2-3005PB | ||||
Two wire system | NO | LMF2-3005LA | |||
NC | LMF2-3005LB | ||||
Detection Distance | |||||
Non-Flush | AC90-250VAC | SCR Control-lable silicon | NO | LMF2-2005A | |
NC | LMF2-2005B | ||||
Control output | DC | 200mA | |||
SCR/Relay | 300mA | ||||
Output vol;tage drop DC/AC | DC (NPN PNP) type 3V or less,Two wire 3.9Vor less, AC 10Vor less DC | ||||
Consumption current | DC (NPN PNP) type 12V 8mA,24V 15mA , AC 10mA or less DC | ||||
standard detected object | 20*20*1 (A3 iron) | ||||
Repeated precision | 0.02 | ||||
DC/AC | 400Hz/25Hz | ||||
Working environment temperature | -25ºC ~ + 75 ºC | ||||
Insulation resistance | 50MΩ | ||||
Shell material | ABS Resin | ||||
Protection grade | IP67 |
