JWK
CE
Winston/OEM
Made-in-China
Export standard carton box
PCS
10
Within 6 days after get payment
6
T/T
| Parameters | Working voltage | Output voltagedrop | Output current | Detection distance | Response frequency | Output form | Shell material and protection grade |
| Type | |||||||
| JWK-A5P | DC：6～36V | ≤1V | 200mA | 5mm | 200Hz | three-wire NOor NC | Plastic ABS lp67 |
| JWK-D5P | |||||||
| JWK-A5PJ | ≤3V | 100mA | two-wire NOor NC | ||||
| JWK-D5PJ | |||||||
| JWK-A10P | DC：6～36V | ≤1V | 200mA | 10mm | 200Hz | three-wire NOor NC | Plastic ABS lp67 |
| JWK-D10P | |||||||
| JWK-A10PJ | ≤3V | 100mA | two-wire NOor NC | ||||
| JWK-D10PJ | |||||||
| JWK200-A1OJ | AC：220V | ≤7V | 3A | 10mm | ≥15Hz | Single NO+NC | Plastic ABS lp67 |
| JWK220-D10J | |||||||
| JWK220-A10JK | Single NO+NC | ||||||
| JWK220-D10JK |
| Parameters | Working voltage | Output voltagedrop | Output current | Detection distance | Response frequency | Output form | Shell material and protection grade |
| Type | |||||||
| JWK-A5P | DC：6～36V | ≤1V | 200mA | 5mm | 200Hz | three-wire NOor NC | Plastic ABS lp67 |
| JWK-D5P | |||||||
| JWK-A5PJ | ≤3V | 100mA | two-wire NOor NC | ||||
| JWK-D5PJ | |||||||
| JWK-A10P | DC：6～36V | ≤1V | 200mA | 10mm | 200Hz | three-wire NOor NC | Plastic ABS lp67 |
| JWK-D10P | |||||||
| JWK-A10PJ | ≤3V | 100mA | two-wire NOor NC | ||||
| JWK-D10PJ | |||||||
| JWK200-A1OJ | AC：220V | ≤7V | 3A | 10mm | ≥15Hz | Single NO+NC | Plastic ABS lp67 |
| JWK220-D10J | |||||||
| JWK220-A10JK | Single NO+NC | ||||||
| JWK220-D10JK |
