E2K-F10MC E2K-F10MF E2K-F10MA0 E2K-F10MAC
WINSTON
Compact volume
Wide voltage range
Diversified exterior structures
high precision of repeated location
Good performance of anti-interference.
Dust proof,vibration proof,waterproof and Oil-proof.
| DETECTION DISTANCE 0-10MM | ||||
| Non-Flush | DC10-30V | NPN | NO | E2K-F10MC1 |
| NC | E2K-F10MC2 | |||
| NO+NC | E2K-F10MC3 | |||
| PNP | NO | E2K-F10MF1 | ||
| NC | E2K-F10MF2 | |||
| NO+NC | E2K-F10MF3 | |||
| AC90-250V | SCR Control-lable silicon | NO | E2K-F10MA0 | |
| NC | E2K-F10MAC | |||
| Control output | DC | 200mA | ||
| SCR/ Relay | 300mA | |||
| Output voltage drop DC/AC | DC<3V AC<10V | |||
| Consumption current | DC<15mA AC<10mA | |||
| Detected object | Conductor and Directric Body | |||
| Repeated precision | 0.05 | |||
| DC/AC Response frequency | 50Hz/10Hz | |||
| Working environment temperature | –25℃~75℃ | |||
| Insulation resistance | 50MΩ | |||
| Shell material | ABS Plastic | |||
| Protection grade | IEC standard IP54 | |||
| Altemative model at home and abroad | ||||
