CM18-3005 CM18-3008
WINSTON
| Flush | Detection distance | 0-5mm | ||
| DC10-30V | NPN | NO | CM18-3005NA | |
| NC | CM18-3005NB | |||
| NO+NC | CM18-3005NC | |||
| PNP | NO | CM18-3005PA | ||
| NC | CM18-3005PB | |||
| NO+NC | CM18-3005PC | |||
| AC90～250V | two wire system | NO | CM18-3005LA | |
| NC | CM18-3005LB | |||
| SCR Control label silicon | NO | CM18-2005A | ||
| NC | CM18-2005B | |||
| Non-flush | Detection distance | 0-8mm | ||
| DC10-30V | NPN | NO | CM18-3008NA | |
| NC | CM18-3008NB | |||
| NO+NC | CM18-3008NC | |||
| PNP | NO | CM18-3008PA | ||
| NC | CM18-3008PB | |||
| NO+NC | CM18-3008PC | |||
| AC90～250V | two wire system | NO | CM18-3008LA | |
| NC | CM18-3008LB | |||
| SCR Control label silicon | NO | CM18-2008A | ||
| NC | CM18-2008B | |||
| Control output | DC | 200mA | ||
| SCR/Relay | 300mA | |||
| Output voltage drop DC/AC | DC<3V AC<10V | |||
| Consumption current | DC<15mA AC<10mA | |||
| Detected object | Conductor and Directric Body | |||
| Repeated precision | 0.05 | |||
| DC/AC Response frequency | 200Hz/25Hz | |||
| Working environment temperature | –25℃～75℃ | |||
| Insulation resistance | 50MΩ | |||
| Shell material | Metal/ABS Resin | |||
| Protection grade | IEC standard IP65/IP67 | |||
| Altemative model at home and abroad | LJC24A3-... | |||
| Flush | Detection distance | 0-5mm | ||
| DC10-30V | NPN | NO | CM18-3005NA | |
| NC | CM18-3005NB | |||
| NO+NC | CM18-3005NC | |||
| PNP | NO | CM18-3005PA | ||
| NC | CM18-3005PB | |||
| NO+NC | CM18-3005PC | |||
| AC90～250V | two wire system | NO | CM18-3005LA | |
| NC | CM18-3005LB | |||
| SCR Control label silicon | NO | CM18-2005A | ||
| NC | CM18-2005B | |||
| Non-flush | Detection distance | 0-8mm | ||
| DC10-30V | NPN | NO | CM18-3008NA | |
| NC | CM18-3008NB | |||
| NO+NC | CM18-3008NC | |||
| PNP | NO | CM18-3008PA | ||
| NC | CM18-3008PB | |||
| NO+NC | CM18-3008PC | |||
| AC90～250V | two wire system | NO | CM18-3008LA | |
| NC | CM18-3008LB | |||
| SCR Control label silicon | NO | CM18-2008A | ||
| NC | CM18-2008B | |||
| Control output | DC | 200mA | ||
| SCR/Relay | 300mA | |||
| Output voltage drop DC/AC | DC<3V AC<10V | |||
| Consumption current | DC<15mA AC<10mA | |||
| Detected object | Conductor and Directric Body | |||
| Repeated precision | 0.05 | |||
| DC/AC Response frequency | 200Hz/25Hz | |||
| Working environment temperature | –25℃～75℃ | |||
| Insulation resistance | 50MΩ | |||
| Shell material | Metal/ABS Resin | |||
| Protection grade | IEC standard IP65/IP67 | |||
| Altemative model at home and abroad | LJC24A3-... | |||
