US-52
Winston
Technical Parameters
Description:
Motor Speed Control use in motor and electric device.
Adjust the rate of stability and mechanical properties.
Corotation/ Reverse Option, connect CW and COM is corotation, Connect CW and CCW is option.
Green LED indicator, on/ off switch for controlling, the knob switch for adjust the speed.
US-52 220V 50Hz Electrical AC Motor Speed Control Pack
Motor Speed Control Pack is widely used in packaging, brushing, food, electronics, the medical instrument,
glasses machinery industry to the production stage machinery velocity modulation driver.
Specifications:
Product Name | Motor Speed Control |
Power | 220V 50HZ |
Material | Plastic, Electrical Material |
Color | Black |
Governor Deflection | 90-1400r/min |
Control Way | Corotation/ Reverse Option |
Fixed Way | Screw Fixed |
Outline Size | 65*155*162mm(L*W*H) |
Cable Length | 68cm |
Weight | 215g |
Package Content | 1 x Motor Speed Control |
Application
