S-350
Winston
This sample cames from winston electric , we specialized in this line for 8 years. The video will show you four keys why choose us next.
Good product is made of good components.
First about capacitor, We use famous brand capacitor which is long life, high stability,safety and relaible.
Second about inductance, we use strong anti-interference type which is thick copper wire, overtcurrent and high inductance.
Third about transformer, we use model EC4045 which is PC40,vacumm dipping,heat uniformity and high strength insulation.
This sample cames from winston electric , we specialized in this line for 8 years. The video will show you four keys why choose us next.
Good product is made of good components.
First about capacitor, We use famous brand capacitor which is long life, high stability,safety and relaible.
Second about inductance, we use strong anti-interference type which is thick copper wire, overtcurrent and high inductance.
Third about transformer, we use model EC4045 which is PC40,vacumm dipping,heat uniformity and high strength insulation.
Model | S-350-5 | S-350-7.5 | S-350-12 | S-350-15 | S-350-24V | S-350-27V | S-350-48 |
Performance | |||||||
DC output voltage | 5V | 7.5V | 12V | 15V | 24V | 27V | 48V |
Output Voltage Tolerance (Note 2) | ±2% | ± 2% | ± 1% | ±1% | ± 1% | ± 1% | ± 1% |
Rated output current | 70A | 46A | 29A | 23.2A | 14.6A | 13A | 7.3A |
Output Current Range | 0-70A | 0-46A | 0-29A | 0-23.2A | 0-14.6A | 0-13A | 0-7.3A |
Ripple and noise (Note 3) | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 200mVp-p | 240mVp-p |
Into the line of stability (Note 4) | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |||
±0.5% | ±0.5% | ±0.5% | |||||
Load stability (Note 5) | ±1% | ± 1% | ± 0.5% | ± 0.5% | |||
±0.5% | ±0.5% | ±0.5% | |||||
DC output power | 350W | 345W | 348W | 348W | 351W | 351W | 350W |
Efficiency | 73% | 76% | 74% | 78% | |||
82% | 82% | 83% | |||||
DC voltage adjustable range | 4.5-5.6V | 6-9V | 10-13.2V | 13.5-18V | 20-26.4V | 26-32V | 41-56V |
Input Voltage Range | 90 ~ 132VAC/180 ~ 264VAC by switch 47-63Hz | ||||||
Input Current | 6.5A /115V,4A /230V | ||||||
Inrush Current | Current 25A/115V 50A/230V cold start | ||||||
Leakage | <3.5mA/240VAC | ||||||
Overload Type | 105% ~ 150% Type: FOLDBACK cut output reset: Automatic restore | ||||||
Over Voltage Protection | 5.75-6.75V | 9.4-10.9V | 13.8-16.2V | 18-21V | 27.6-32.4V | 33.7-39.2V | 57.6-67.2V |
Temperature Protection | ERH3>=65°C-70°C Fan on,<=55°C-60°C Fan off,>=80°C-85°C Cut off output(5-15V)-(24-48V) | ||||||
Temperature Coefficient | ± 0.03%/ °C (0 ~ 50°C ) | ||||||
Start, rise, hold time | 200ms,100ms,30ms | ||||||
Earthquake resistance | 10 ~ 500Hz, 2G 10min. / 1 cycle, duration 60 minutes, each axis | ||||||
Pressure of | Between input and output: 1.5KvAC, input and shell: 1.5KvAC, output and shell: 0.5KvAC | ||||||
Isolation Resistance | Input and output, input and shell, shell and output: 500VDC/100M Ohms | ||||||
Temperature, humidity | -10°C~ + 60°C,20% ~ 90%RH | ||||||
Storage temperature, temperature | -20°C ~ + 85°C,10% ~ 95%RH | ||||||
Dimensions | 215*115*50mm | ||||||
Weight | 1.15Kgs | ||||||
Safety Standards | To meet UL1012 requirements | ||||||
EMC Standards | To meet the FCC PART15JCONDUCTION CLASS B |
Model | S-350-5 | S-350-7.5 | S-350-12 | S-350-15 | S-350-24V | S-350-27V | S-350-48 |
Performance | |||||||
DC output voltage | 5V | 7.5V | 12V | 15V | 24V | 27V | 48V |
Output Voltage Tolerance (Note 2) | ±2% | ± 2% | ± 1% | ±1% | ± 1% | ± 1% | ± 1% |
Rated output current | 70A | 46A | 29A | 23.2A | 14.6A | 13A | 7.3A |
Output Current Range | 0-70A | 0-46A | 0-29A | 0-23.2A | 0-14.6A | 0-13A | 0-7.3A |
Ripple and noise (Note 3) | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 150mVp-p | 200mVp-p | 240mVp-p |
Into the line of stability (Note 4) | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |||
±0.5% | ±0.5% | ±0.5% | |||||
Load stability (Note 5) | ±1% | ± 1% | ± 0.5% | ± 0.5% | |||
±0.5% | ±0.5% | ±0.5% | |||||
DC output power | 350W | 345W | 348W | 348W | 351W | 351W | 350W |
Efficiency | 73% | 76% | 74% | 78% | |||
82% | 82% | 83% | |||||
DC voltage adjustable range | 4.5-5.6V | 6-9V | 10-13.2V | 13.5-18V | 20-26.4V | 26-32V | 41-56V |
Input Voltage Range | 90 ~ 132VAC/180 ~ 264VAC by switch 47-63Hz | ||||||
Input Current | 6.5A /115V,4A /230V | ||||||
Inrush Current | Current 25A/115V 50A/230V cold start | ||||||
Leakage | <3.5mA/240VAC | ||||||
Overload Type | 105% ~ 150% Type: FOLDBACK cut output reset: Automatic restore | ||||||
Over Voltage Protection | 5.75-6.75V | 9.4-10.9V | 13.8-16.2V | 18-21V | 27.6-32.4V | 33.7-39.2V | 57.6-67.2V |
Temperature Protection | ERH3>=65°C-70°C Fan on,<=55°C-60°C Fan off,>=80°C-85°C Cut off output(5-15V)-(24-48V) | ||||||
Temperature Coefficient | ± 0.03%/ °C (0 ~ 50°C ) | ||||||
Start, rise, hold time | 200ms,100ms,30ms | ||||||
Earthquake resistance | 10 ~ 500Hz, 2G 10min. / 1 cycle, duration 60 minutes, each axis | ||||||
Pressure of | Between input and output: 1.5KvAC, input and shell: 1.5KvAC, output and shell: 0.5KvAC | ||||||
Isolation Resistance | Input and output, input and shell, shell and output: 500VDC/100M Ohms | ||||||
Temperature, humidity | -10°C~ + 60°C,20% ~ 90%RH | ||||||
Storage temperature, temperature | -20°C ~ + 85°C,10% ~ 95%RH | ||||||
Dimensions | 215*115*50mm | ||||||
Weight | 1.15Kgs | ||||||
Safety Standards | To meet UL1012 requirements | ||||||
EMC Standards | To meet the FCC PART15JCONDUCTION CLASS B |
