WST-C10D
Winston
| Ex mark | Ex de II C T6 DIP A21 TA,T6 | |
| Application | zone 1 and zone 2 | |
| Ambient temperature | -60℃≤Ta≤55℃ | |
| Degree of protection | IP67(Match operation head) | |
| Button | ||
| Conventional enclosed thermal current | 10A | |
| Rated voltage | 250V | 24V |
| Category | AC15 | AC13 |
| Rated current | 6A | 1A |
| Mechanical life | 300,000 times | |
| Signal lamp | ||
| Light source | LED | |
| Power consumption | Pmax≤1W | |
| Rated voltage | AC.DC6.3V-220V AC110V-380V | |
| Electric life | 300,000 hours | |
| Standard | Standard | |
1. Hazardous areas: Zone 1&2 or zone 20、 21、 22;
2. Explosive gas atmosphere: class IIA. IIB. IIC;
3. Flammable dust atmospheres;
4.Strong corrosive gas environment;
1. The shell is made by customized engineering plastics.
2. Transparent cover is made by polycarbonate
3. LED light source is used in explosion-proof signal lamp. It has more than 300,000 hours life time, with good performance of energy saving, and environmental protection.
4. This product should be used together with increased safety enclosure or explosion-proof box, can't be used separately.
| Ex mark | Ex de II C T6 DIP A21 TA,T6 | |
| Application | zone 1 and zone 2 | |
| Ambient temperature | -60℃≤Ta≤55℃ | |
| Degree of protection | IP67(Match operation head) | |
| Button | ||
| Conventional enclosed thermal current | 10A | |
| Rated voltage | 250V | 24V |
| Category | AC15 | AC13 |
| Rated current | 6A | 1A |
| Mechanical life | 300,000 times | |
| Signal lamp | ||
| Light source | LED | |
| Power consumption | Pmax≤1W | |
| Rated voltage | AC.DC6.3V-220V AC110V-380V | |
| Electric life | 300,000 hours | |
| Standard | Standard | |
1. Hazardous areas: Zone 1&2 or zone 20、 21、 22;
2. Explosive gas atmosphere: class IIA. IIB. IIC;
3. Flammable dust atmospheres;
4.Strong corrosive gas environment;
1. The shell is made by customized engineering plastics.
2. Transparent cover is made by polycarbonate
3. LED light source is used in explosion-proof signal lamp. It has more than 300,000 hours life time, with good performance of energy saving, and environmental protection.
4. This product should be used together with increased safety enclosure or explosion-proof box, can't be used separately.
