MS-190
Winston
8531809000
MS-190 DC Motor Alarm Siren
Description
Apply in small elevator, conveyor, the place such as small vessels mechanical warehouse to send signals.
Color:Red&Grey
Material:Metal or ABS
Insulation resistance:100MΩ at 500Vdc
Withstand voltage:500VAC,50/60HZ in 1 minute
Power:40W
IP grade:IP44
Technical parameters
Model | Voltage | Current(A) | HZ | dB(A)1m | Packing size | PCS/CTN | G.W. |
MS-190 | DC12V | 6.00 | 50/60 | 114dB | 44.5*23*48cm | 40PCS | 16KG |
DC24V | 2.50 | 50/60 | 114dB | 16KG | |||
AC110V | 0.90 | 50/60 | 114dB | 22KG | |||
AC220V | 0.43 | 50/60 | 114dB | 22KG |
Overall dimensions
