MS-190 DC Motor Alarm Siren

Electric Moter Alarm Siren with the external diameter of 80/100mm which makes the output of 40W sound volume.
Suitable for warning information of small hoist, light transfer cars and the inside of small vessel.
Body standard color : RED
Material : STEEL & ABS
Insulation resistance : 100MΩ(at 500 VDC)
Dielectric strength : 500VAC, 50/60Hz in 1 minute
Protection class : IP44

Price: $ 0
Discount Price: $ 0
Quantity:
  • MS-190
  • Winston
  • 8531809000

MS-190 DC Motor Alarm Siren

Description

Apply in small elevator, conveyor, the place such as small vessels mechanical warehouse to send signals.
Color:Red&Grey
Material:Metal or ABS
Insulation resistance:100MΩ at 500Vdc
Withstand voltage:500VAC,50/60HZ in 1 minute
Power:40W
IP grade:IP44


Technical parameters


       Model        Voltage        Current(A)        HZ        dB(A)1m        Packing size        PCS/CTN        G.W.
       MS-190        DC12V        6.00        50/60        114dB        44.5*23*48cm        40PCS        16KG
       DC24V        2.50        50/60        114dB        16KG
       AC110V        0.90        50/60        114dB        22KG
       AC220V        0.43        50/60        114dB        22KG


Overall dimensions

                      QQ图片20140325151745
