Electric Wireless AC Vehicle Car Ev Charger Charging Stations 7kw

Electric Wireless AC Vehicle Car Ev Charger Charging Stations 7kw

Scope Of Application

The AC charging station provides AC 50Hz, rated voltage 220V AC power supply for charging electric vehicles with on-board chargers, and is  mainly suitable for the following places:
Large, medium and small electric vehicle charging stations;
Various public places with parking spaces for electric vehicles, such as urban residential communities, shopping plazas, and power business places;
Transportation hub areas such as high-speed service areas, stations and docks;
Real estate and project construction acceptance needs.

Features

• Provide two installation methods: column type and wall type;
• Adopt AC220V AC input;
• The main control board uses a single-chip microcomputer with an embedded operating system, and the charging mode is divided into automatic charging and charging mode
• There are four types of time, choice of charging amount, and choice of charging power. RS-485 networking can be reserved
• Communication interface, and provide optional GPRS, 4G and other networking methods.
• It adopts a 4.3-inch display screen and can set the charging mode (the display screen is only available in the operating version);
• Single-phase electronic electric energy meter is used for electricity metering, and communicates with the main control board through the RS-485 interface;
• Adopt non-contact smart card reader to read IC card related information and communicate with main control board through RS-485 interface,
• The main control board background program performs the identity identication, user information recording, and charging
• Electricity cost calculation, etc.; the incoming switch adopts a switch with leakage protection function, and installs anemergency stop button (swiping card power
• Can only be provided for the swiping version and the operating version);
• The shape adopts sheet metal and part of ABS plastic structure.

Technical Parameters
