PS-25W

Quantity:
Low price and high reliability 105℃ output capacitor AC input power suitable for the world High efficiency and low operation temperature Soft-start current can reduce the AC input impact effecticly With short -circuit and overload protection Compact size, light weight 100% full-load buming test Installed with EMI filter,minimum wave




       AC input voltage range:90-264VAC,47-63Hz ,120-370VDC
        AC inrush current: Cold-start current 20A/115V.40A/230VAC
        Overload protection:105%~150% Type:plusing hiccup shutdown Reset:auto recovery
        Setup rise hold-up time:200ms,50ms,20ms
        Vibration:10~500Hz,2G 10min,/1cycle,Period for 60min,Each axes
        Withstand voltage:Input and Cold internal 3KVAC ,Output and east :1.5KVAC
        Isolation resistance:Input and output internal,input and enclosure,output and enclosure:500VDC/100MΩ
        Working temperature and humidity:-10℃~+50℃@100% ,-10`c@50%   20%~90%RH
       Connection Method        Output:2road3.96mmPin input         input:6road 3.96mmpin
        Weight:0.22Kgs 54PCS/14.2Kg/1.35CUFT
        Safety standards:Meet UL60950-1.TUVEN60950-1 approved


          EMC :EN5022 CLASS B EN61000-3-2-3     EN61000-4-2.3.4.5.6.8.11 ENV50204






               MODEL                Ps-65-5                Ps-65-12                Ps-65-15                Ps-65-24
                DC output voltage                5V                12V                15V                24V
                Output voltage error                ±1%                ±1%                ±1%                ±1%
                Rated output current                12A                5.2A                4.3A                2.7A
               Load Stability                ±3%                ±2%                ±2%                ±2%
               Wave and noise                100mV                100mV                100mV                100mV
                DC output power                60W                65W                65W                65W
               Efficiency                76%                79%                80%                80%
