MS-290A
Winston
8531809000
MS-290A Plastic Motor Alarm Siren
Description
Apply in small elevator, conveyor, the place such as small vessels mechanical warehouse to send signals.
Color:Grey
Material:ABS
Insulation resistance:100MΩ at 500Vdc
Withstand voltage:500VAC,50/60HZ in 1 minute
Power:40W
IP grade:IP44
Technical parameters
| Model | Voltage | Current(A) | HZ | dB(A)1m | Packing size | PCS/CTN | G.W. |
| MS-290A | DC12V | 5.8 | 60 | 112dB | 54*34*41cm | 24PCS | 18KG |
| DC24V | 2.1 | 60 | 112dB | 18KG | |||
| AC110V | 1.6 | 60 | 112dB | 18KG | |||
| AC220V | 0.8 | 60 | 112dB | 18KG |
Overall dimensions
Character
Duration: sustainable working time to 40 minutes or more.
