| Quantity: | |
|---|---|
Compact volume
Wide voltage range
Diversified exterior structures
high precision of repeated location
Good performance of anti-interference.
Dust proof,vibration proof,waterproof and Oil-proof.
| Model | Two-wire normally close | AM8-3001LB |
| Specification | Rated Vollage | 8.2V |
| Sensing Range | 1mm | |
| Standard Object Q235 steel(mm) | 12*12*1t | |
| Oscillating /Stop Pscillating Current | ≥2.2mA/≤1mA | |
| load resistance | 1KΩ | |
| Switch frequency, Flush | 1.5Hz | |
| Shell material | Nickel-plated brass | |
| Protection Level | IP67 | |
| working environment temperature | -20ºC~70ºC | |
| External wiring diagram |
Compact volume
Wide voltage range
Diversified exterior structures
high precision of repeated location
Good performance of anti-interference.
Dust proof,vibration proof,waterproof and Oil-proof.
| Model | Two-wire normally close | AM8-3001LB |
| Specification | Rated Vollage | 8.2V |
| Sensing Range | 1mm | |
| Standard Object Q235 steel(mm) | 12*12*1t | |
| Oscillating /Stop Pscillating Current | ≥2.2mA/≤1mA | |
| load resistance | 1KΩ | |
| Switch frequency, Flush | 1.5Hz | |
| Shell material | Nickel-plated brass | |
| Protection Level | IP67 | |
| working environment temperature | -20ºC~70ºC | |
| External wiring diagram |
