12w
CE
Winston/OEM
Made in China
Export standard carton box
PCS
100
3-15days
1
T/T
| Output | |||||||||
| DC Voltage | 12V± 3% | ||||||||
| Rated Current | 1A | ||||||||
| Ripple &Noise(Max) | mVp-p 1%Uout | ||||||||
| Load regulation | ±1% | ||||||||
| Setup rise Hold up Time | 230V/500ms 20ms 30ms | ||||||||
| 115V/500ms 20ms 10ms | |||||||||
| Input | |||||||||
| Voltage Range | 95-264VAC | ||||||||
| Frequency Range | 47-63Hz | ||||||||
| Efficiency | ＞0.75 | ||||||||
| AC Current | 40A/230V | ||||||||
| Prodection | |||||||||
| Short Circuit prodection | |||||||||
| Over Load | 130%-150% | ||||||||
| Over Voltage | 115%-135% | ||||||||
| Environment | |||||||||
| Working Temp. | 0-50 ℃ | ||||||||
| Working Humidity | 20%-90% RH | ||||||||
| Storage Temp Humidity | 20%-95% RH | ||||||||
| Safety&EMC | |||||||||
| Safety Standards | FCC,UL,GB4943 | ||||||||
| Withstand Voltage | IP/OP 5mA 2KVAC | ||||||||
| Isolation Resistance | IP/OP 100M Ohms | ||||||||
| Others | |||||||||
| Dimension | 74*46*30mm | ||||||||
| Weight | 105g | ||||||||
| Packing | |||||||||
| Typical model list | |||||||||
| Model | 3.3V3A | 5V1A | 5V2A | 6V1A | 7.5V1A | 7.5V1.5A | 9V1A | 12V1A | 24V0.5A |
| Output rating | 10W | 5W | 10W | 6W | 8W | 12W | 10W | 12W | 12W |
| Output voltage | 3.3V | 5V | 5V | 6V | 7.5V | 7.5V | 9V | 12V | 24V |
| Output current | 3A | 1A | 2A | 1A | 1A | 1.5A | 1A | 1A | 0.5A |
| Voltage tolerance | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% | ±5% |
