Yueqing SMPS DR-15 Din Rail 12V 24V 15W Power Supply

Availability:
Quantity:
  • DR-15

  • Winston/OEM

Features

Universal AC input / Full range

Protections: Short circuit / Overload / Over voltage / Over temperature

Cooling by free air convection

Can be installed on DIN rail TS-35/7.5 or 15

LED indicator for power on

100% full load burn-in test

2 years warranty


Technical data

SPECIFICATIONS
OUTPUT
Model DR-15-5 DR15-12 DR-15-15 DR-15-24
DC Voltage  5V 12V 15V 24V
Rated Current  2.4A 1.25A 1A 0.63A
Current Range  0-2.4A 0-1.25A 0-1A 0-0.63A
Rated Power  12W 15W 15W 15.2W
Ripple & Noise  80mVp-p 120mVp-p 120mVp-p 150mVp-p
Voltage Adj. Range 4.75-5.5V 10.8-13.2V 13.5-16.5V 21.6-26.4V
Voltage Tolerance  ±2% ±1% ±1% ±1%
Line regulation ±1% ±1% ±1% ±1%
Load regulation ±1% ±1% ±1% ±1%
Setup, Rise, Hold Up Time  1000ms, 50ms/230VAC 1000ms, 50ms/115VAC at full load  70ms/230VAC          16ms/115VAC at full load


INPUT
Voltage Range  85 ~ 264VAC          120 ~ 370VDC
AC Current 0.88A/115VAC          0.48A/230VAC
Efficiency 77% 84% 83.50% 85%
Inrush Current  COLD START 35A/115VAC          65A/230VAC


PROTECTION
Over Load  105%~160% rated output power
Protection type: Constant current limiting, recovers automatically after fault condition is removed
Over Voltage  5.75-6.75V 13.8-16.2V 17.25-20.25V 27.6-32.4V
Protection type: Shut off o/p voltage, clamping by zener diode


ENVIRONMENT
Working Temp., Humidity -20℃~+60℃; 20%~90% RH non-condensing
Storage Temp., Humidity -40℃~+85℃; 10%~95%RH
Temp. Coefficient ±0.03%/℃(0~50℃)
Vibration 10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes, Mounting: Compliance to IE60068-2-6


SAFETY
Withstand Voltage I/P-O/P: 3KVAC
Isolation Resistance I/P-O/P: 100M Ohms / 500VDC/ 25℃/ 70%RH


STANDARD
Safety Standard Design refer to UL60950-1,TUV EN60950-1,EN50178
EMC Standard Design refer to EN55011,EN55022,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,EN55024,EN61000-6-2,EN61204-3, heavy industry level, criteria A


OTHERS
Dimension 25*93*56mm(W*H*D)
Weight 0.1Kg
Packing 140pcs/15KG/0.92CUFT


NOTE
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12” twisted pair-wire terminated with a 0.1μ & 47μ parallel capacitor.
3. Tolerance: includes set up tolerance, line regulation and load regulation.
