WSTR7
Winston
Widely Use Weekly Programming Room Thermostat WSTR7
Weekly Programming Room Thermostat Weekly circulation, it is possible to set 6 periods called events each day with corresponding pre-set temperatures, also you can select "period control mode" or "manual mode" according to your individual requirements. The thermostat is recommended for the control of electric heating devices or on/off valve actuator used in water-based heating systems.
Technical Parameter
Voltage | 230VAC/110VAC/24VAC, 50/60Hz |
Power Consumption | 2W |
Setting Range | 5ºC---90ºC |
Limitation Range | 5ºC--99ºC (factory setting 35ºC) |
Accuracy of temperature measurement | 0.5~10 Adjustable, factory setting±1ºC |
Ambient temperature | -5~50ºC |
Protective housing | IP20 |
Housing material | Self-extinguishing PC |
Selection Table | ||||||||
Model | Current | Application | ||||||
WSTR713 | 3A | Built-in&Floor Sensor, floor limiy sensor,period programming | ||||||
WSTR723 | 3A | Built-in&Floor Sensor, floor limiy sensor,period programming, a potential-free output | ||||||
WSTR716 | 16A | Built-in&Floor Sensor, floor limiy sensor,period programming | ||||||
WSTR703 | 3A | A pair of contacts for potential-free output |
Product Description
Dimension
Application
Package and Shipping
