Manufacturer Plastic Inductive Poximity Linear Switch XMF37 With CE

Quantity:
  • XMF37
  • Winston


Technic data

XMF37 Detection   Distance 15mm 20mm
Current   type DC15-30VDC                                      XMF37-3015PMI XMF37-3020PMI
Voltage   type DC15-30VDC                                      XMF37-3015PMU XMF37-3020PMU
Consumption at the time of detection 200mA…4mA
at the time   of non-detection 20mA
Loading resistance Current type 0-300Ω
Voltage type 2.2KΩ
Output Current type 4-20mA
Voltage type 0-5V/0-10V
Voltage fluctuation ≤5%
Output signal PNP Simulation
Linear deviation ±5%
Ambient temperature —10 ~ + 70
Shell material Plastic,Metal
Protection grade IP54


Dimension



Application
