Inductive Proximity Sensor Shielded Type PNP NO (LM5-3001PA)

Quantity:
  • LM5-3001PA
  • Winston

Inductive Proximity Sensor Shielded Type PNP NO (LM5-3001PA)

Trade

Inductive Proximity Sensor PNP 2mm Distance With Connector (LM8-T3)

Technical Parameters

Inductive Proximity Sensor PNP 2mm Distance With Connector (LM8-T3)

LM5 Detection Distance 1mm
Flush

DC10-30VDC

 (6-36VDC)

NPN NO LM5-3001NA
NC
NO+NC
PNP NO LM5-3001PA
NC
NO+NC
Two wire system NO
NC
AC90-250VAC SCR Control-lable silicon NO
NC
NO+NC
Relay output
Control  output DC 200mA
SCR/Relay
Output vol;tage drop DC/AC

DC (NPN PNP) type 3V or less,Two wire 3.9Vor less,

AC 10Vor less DC<3V AC>10V

Consumption current

DC (NPN PNP) type 12V 8mA,24V 15mA ,

AC 10mA or less DC<15mA, AC>10mA

standard detected object 6*6*1 (A3 iron)
Repeated precision 0.01
DC/AC 500Hz
Working environment temperature —25℃ ~ + 75 ℃
Insulation resistance 50MΩ
Shell material Metal
Protection grade IP67



M5 Inductive Proximity Sensor 1mm Distance PNP / NPN NO (LM5-3001NA)

Wiring diagram

Inductive Proximity Sensor PNP 2mm Distance With Connector (LM8-T3)

Packaging & Shipping

Inductive Proximity Sensor PNP 2mm Distance With Connector (LM8-T3)

Certifications

Inductive Proximity Sensor PNP 2mm Distance With Connector (LM8-T3)

About us

Inductive Proximity Sensor PNP 2mm Distance With Connector (LM8-T3)

Why choose us

Inductive Proximity Sensor PNP 2mm Distance With Connector (LM8-T3)



Professional manufacturer, quality is our culture!
