CSK4-NKW
Winston
Cover:Polyphenylene Oxide
Gear:Polyoxymethylene
Digial: Polycarbonate
Bracket:Fingerprint resistant material
Model | CSK4-NKW |
Counting range | 0-9999 |
Voltage type | DC24V, AC220V |
Voltage fluctuation range | ±10% |
Counting speed | 10 times/sec |
Indication error | <1*0.00001 |
Working enviroment temperature | -20°C~50°C Relative temperature: ≤85% |
Power | DC1.5W, AC2.5W |
Install | Clasp type |
Cover:Polyphenylene Oxide
Gear:Polyoxymethylene
Digial: Polycarbonate
Bracket:Fingerprint resistant material
Model | CSK4-NKW |
Counting range | 0-9999 |
Voltage type | DC24V, AC220V |
Voltage fluctuation range | ±10% |
Counting speed | 10 times/sec |
Indication error | <1*0.00001 |
Working enviroment temperature | -20°C~50°C Relative temperature: ≤85% |
Power | DC1.5W, AC2.5W |
Install | Clasp type |
Model | CSK4-NKW |
Counter range | 0-9999 |
Voltage | AC220V,AC110V,DC24V,DC12V,Custom |
Counter speed | DC 20times/s;AC 10times/S |
Indication error | <1*0.00001 |
Use environment | -20°C~50°C ≤85% |
Power | DC1.5W;AC2.5W |
Installation method | Panel mounting |
Return to zero mode | Pushbutton return to zero (with lock) |
Model | CSK4-NKW |
Counter range | 0-9999 |
Voltage | AC220V,AC110V,DC24V,DC12V,Custom |
Counter speed | DC 20times/s;AC 10times/S |
Indication error | <1*0.00001 |
Use environment | -20°C~50°C ≤85% |
Power | DC1.5W;AC2.5W |
Installation method | Panel mounting |
Return to zero mode | Pushbutton return to zero (with lock) |
