CSF032 Compact high-performance Fan Heater

Share to:

CSF032 Compact high-performance Fan Heater

Quantity:



Inquire Add to Basket

Model:
CSF032
Trademark:
Winston
Origin:
Made in China
Packing:
Export standard carton box
Unit:
PCS
Min order:
1
TransTime:
3-7days
Transportation:
1
Payment:
T/T

Compact high-performance Fan Heater Series CSF 032 Low surface temperature Integrated thermostat Quick mounting due to clip fixing Double insulated (plastic) Wide voltage range Small size Touch-safe heater for the use in enclosures with electrical/electronical components. The design of the heater supports the natural convection which results in a high air-current of warm air. The surface temperatures on the accessible side surfaces of the housing are kept down as a result of the heater design. This model with plug-in thermostat does not require additional wiring. The heaters are designed for permanent operation. This heater is also available in a version without thermostat (CS 060).

Technical Data

Heating element	PTC resistor - temperature limiting
Surface temperature	max. 80°C (176°F), except upper protective grille
	at 20°C (68°F) ambient temperature
Air outlet temperature	max. 110°C (212°F), 50mm above the grille
Temperature safety cut-out	to protect against overheating in case of fan failure,
	automatic reset
Axial fan, ball bearing	air flow 63m⊃3;/h, free flow
	service life 70,000h at 25°C (77°F)
Connection	male power insert connector according to IEC320 C18
Fuse	10A time lag (T) integrated in connector - exchangeable
Casing	plastic according to UL94 V-0, black
Mounting	clip for 35mm DIN rail, EN 60715 or
	screw fixing (M5), tightening torque 2Nm max.
Fitting position	airflow direction up
Dimensions	150.5 x 88 x 66mm
Weight	approx. 0.5kg
Operation/Storage temperature	-40 to +60°C (-40 to +140°F) / -40 to +70°C (-40 to +158°F)
Operation/Storage humidity	max. 90% RH (non-condensing)
Protection type/Protection class	IP20 / II (double insulated)
Approvals

Art. No. clip fixing	Art. No. screw fixing	Operating voltage	Heating capacity⊃1;	Inrush current max.	Switch-off temoperature⊃2;	Switch-on temperature⊃2;
03201.0-00	03201.0-01	220-240VAC, 50/60Hz	1,000W	12A	+25°C (77°F)	+15°C (59°F)
03202.0-00	03202.0-01	220-240VAC, 50/60Hz	1,000W	12A	+15°C (59°F)	+5°C (41°F)
03201.9-00	03201.9-01	100-120VAC, 50/60Hz	1,000W	18A	+25°C (77°F)	+15°C (59°F)
03202.9-00	03202.9-01	100-120VAC, 50/60Hz	1,000W	18A	+15°C (59°F)	+5°C (41°F)
