S-15-5 S-15-12 S-15-15 S-15-24
WINSTON
AC input power suitable for the world
Hight efficiency and low operation temperature
Compact size,light weight
100% full-load burning test
Installed with EMI filter,minimum wave
| Model | S-15-5 | MS-15-12 | MS-15-15 | MS-15-24 | |
| Output | DC Voltage | 5V | 12V | 15V | 24V |
| Current Range | 0~3A | 0~1.3A | 0~1A | 0~0.7A | |
| Wave & Noise | 50mVp-p | 50mVp-p | 75mVp-p | 100mVp-p | |
| Voltage Adj.Range | ±10% | ±10% | ±10% | ±10% | |
| Line wave stability | ±0.5% | ±0.5% | ±0.5% | ±0.5% | |
| Load stability | ±1.0% | ±0.5% | ±0.5% | ±0.5% | |
| Setup,Rise time | 300ms, 50ms/230VAC 800ms, 50ms/115VAC at full load | ||||
| Hold time | 90ms/230VAC 12ms/115VAC at full load | ||||
| Input | Voltage Range | 85 ~ 264VAC 120 ~ 370VDC 47~63HZ | |||
| Efficiency | 65%/115VAC | 68%/115VAC | 70%/115VAC | 72%115VAC | |
| Impact Current | Cold Start Current 30A/230VAC | ||||
| Leakage Current | <0.75mA / 240VAC | ||||
| Protection | Over Load | 105 ~ 150% Cut off the output, Automatic Recovery | |||
| Environment | Working Temperature | -10 ~ +50°c (Refer to "Derating Curve" ) | |||
| Working Humidity | 20~90% RH Non-condensing | ||||
| Temp. coefficient | ±0.03%/°C (0~50°C) | ||||
| Safety | Withstand Voltage | I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC | |||
| Isolation Resistance | I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC/ 25°c / 70% RH | ||||
| Weight | 0.3kg | ||||
| Others | Dimension | 98*97*35mm (L*W*H) | |||
| Packing | 43*32.5*24CM/60PCS/18Kg | ||||
